(米亞基逆變直流焊接電源)SDN-444C型 逆變換向器自動點焊機
SDN-444C Commutator Automatic Spot Welding Machine (DC output)
本機是專為電機換向器與電樞繞組焊接的一種專用焊機。采用三菱PLC控制器和觸摸屏顯示器控制焊機動作,配置米亞基逆變焊機控制、可定電流、定功率、定電壓等控制,多段通電方式。具有電流緩升、緩降功能。
Suitable for motor commutator and armature winding welding of a special welder.Mitsubishi PLC controller and touch screen display control welding movements, Miyachi inverter welding machine control, constant current, constant power, constant voltage control,multi-stage power mode. With the current slow rise, slow down function.
技術參數/Technicai Parameters
電源電壓Supply voltage | AC380V±10% 50Hz |
氣源壓力Air pressure |
0.5~0.7 Mpa |
焊機功率Welder power |
150kw |
焊接電流Welding current |
20000A |
可焊線徑Wire diameter |
≤Φ4.0mm |
轉子直徑Rotor Diameter |
≤Φ130mm |
轉子軸徑Rotor shaft diameter |
≤Φ22mm |
換向器直徑Commutator diameter |
≤Φ80mm |
